AFIM DRY - A suitable solution for every situation
The AFIM Dry series has been developed for application within the industry where quality and reliability are self-evident. In addition to this high reliability, various innovative energy savings have been integrated into the AFIM Dry series.
| Dehumidifier type | Capacity (kg/h) | Dry air flow (m3/h) | Nominal electrical power (kW) | Energy class | Energy class with HRU | Brochure |
|---|---|---|---|---|---|---|
| AFIM Dry 1000 | 10 | 1000 | 14.8 | A+ (1,29 kW / kg) | Not applicable | Download |
| AFIM Dry 2000 | 20 | 2000 | 26 | A+ (1,06 kW / kg) | A++ (0,77 kW / kg) | Download |
| AFIM Dry 3500 | 30 | 3500 | 36 | A+ (1,10 kW / kg) | A++ (0,86 kW / kg) | Download |
| AFIM Dry 5000 | 50 | 5000 | 56 | A+ (1,06 kW / kg) | A++ (0,86 kW / kg) | Download |
| AFIM Dry 10K | 70 | 10000 | 92 | A+ (1,16 kW / kg) | A++ (0,92 kW / kg) | Download |
The AFIM Dry 1000 desiccant dehumidifier is equipped as standard with an integrated and energy-efficient EC fan. In addition, the dehumidifier is suitable for use in industrial environments and is equipped with filters that contain up to 5x higher dust absorption capacity.
By applying EC technology in combination with both internal heat recovery (standard) and also the possibility for external heat recovery (optional), the AFIM Dry is one of the most energy-efficient dehumidifiers on the market.
Standard for the AFIM Dry 1000
- Suitable for industrial environments
- Digital controller (suitable for 2 step control)
- Low maintenance costs due to filters with up to 5 times higher dust absorption capacity
- Suitable for application within the food and pharmaceutical industry and storage applications
- Internal heat recovery (energy saving up to 15% compared to market standard)
- Suitable for very low dew points (up to -60ºC dp)
- Internal operating hours counter
- Original Dutch product
Optional for the AFIM Dry 1000
- External heat recovery (energy saving up to 43% compared to market standard)
- Fully executed in stainless steel 304 or 316
- Filter alarm
- 5 year warranty extension
- Online assistance
- Online monitoring
| Technical specifications | ||
|---|---|---|
| Dehumidification capacity | 10 kg/h | (at +20°C and 60% RH) |
| Process airflow | 1000 m3/h | (at 500 Pa external pressure available) |
| Regeneration airflow | 400 m3/h | (at 500 Pa external pressure available) |
| Filter class | ePM1 50% (F7) | (according to ISO standard 16890) |
| Heater power | 13.5 kW | (maximum) |
| Nominal electrical power | 14.8 kW | |
| Electrical power supply | 17 kW | (3× 400 VAC, 50 Hz, 4-wire) |
| Nominal noise level | 60 dB(A) | (on 1 meter distance) |
| Dimensions | 1650 x 850 x 1500 | (WxDxH in mm) |
| Weight | 450 kg | |
The AFIM Dry 2000 desiccant dehumidifier is standard equipped with a flow controlled control of the process fan, so filter pollution does not affect the operation of the dehumidifier. In addition, the dehumidifier is suitable for use in industrial environments and is equipped with filters that contain up to 5x higher dust absorption capacity.
By applying EC technology in combination with both internal heat recovery (standard) and also the possibility for external heat recovery (optional), the AFIM Dry is one of the most energy-efficient dehumidifiers on the market.
Standard for the AFIM Dry 2000
- Suitable for industrial environments
- Digital controller (suitable for 2 step control)
- Low maintenance costs due to filters with up to 5 times higher dust absorption capacity
- Suitable for application within the food and pharmaceutical industry and storage applications
- Internal heat recovery (energy saving up to 15% compared to market standard)
- Suitable for very low dew points (up to -60ºC dp)
- Internal operating hours counter
- Original Dutch product
Optional for the AFIM Dry 2000
- External heat recovery (energy saving up to 43% compared to market standard)
- Fully executed in stainless steel 304 or 316
- Filter alarm
- 5 year warranty extension
- Online assistance
- Online monitoring
| Technical specifications | ||
|---|---|---|
| Dehumidification capacity | 20 kg/h | (at +20°C and 60% RH) |
| Process airflow | 2000 m3/h | (at 500 Pa external pressure available) |
| Regeneration airflow | 700 m3/h | (at 1000 Pa external pressure available) |
| Filter class | ePM1 50% (F7) | (according to ISO standard 16890) |
| Heater power | 22,5 kW | (maximum) |
| Nominal electrical power | 26 kW | |
| Electrical power supply | 26,5 kW | (3× 400 VAC, 50 Hz, 4-wire) |
| Nominal noise level | 69 dB(A) | (on 1 meter distance) |
| Dimensions | 2130 x 1270 x 1990 | (WxDxH in mm) |
| Weight | 475 kg | |
The AFIM Dry 3500 desiccant dehumidifier is standard equipped with a flow controlled control of the process fan, so filter pollution does not affect the operation of the dehumidifier. In addition, the dehumidifier is suitable for use in industrial environments and is equipped with filters that contain up to 5x higher dust absorption capacity.
By applying EC technology in combination with both internal heat recovery (standard) and also the possibility for external heat recovery (optional), the AFIM Dry is one of the most energy-efficient dehumidifiers on the market.
Standard for the AFIM Dry 3500
- Suitable for industrial environments
- Fully insulated and unique thermal bridge-free housing
- Analog controller (suitable for 0-10 Volt DC)
- No hindrance from filter pollution due to constant volume control
- Low maintenance costs due to filters with up to 5 times higher dust absorption capacity
- Suitable for application within the food and pharmaceutical industry and storage applications
- Internal heat recovery (energy saving up to 15% compared to market standard)
- Suitable for very low dew points (up to -60ºC dp)
- Various adjustable digital calendar clocks
- Filter alarm
- Rotor rotation guard
- Digital alarm history including time and date stamp
- Different operating hours counters (individual for each main component in the dehumidifier)
- Original Dutch product
Optional for the AFIM Dry 3500
- External heat recovery (energy saving up to 43% compared to market standard)
- Fully executed in stainless steel 304 or 316
- 5 year warranty extension
- Online assistance
- Online monitoring
| Technical specifications | ||
|---|---|---|
| Dehumidification capacity | 30 kg/h | (at +20°C and 60% RH) |
| Process airflow | 3500 m3/h | (at 500 Pa external pressure available) |
| Regeneration airflow | 1100 m3/h | (at 1000 Pa external pressure available) |
| Filter class | ePM1 50% (F7) | (according to ISO standard 16890) |
| Heater power | 31,5 kW | (maximum) |
| Electrical power supply | 36 kW | (3× 400 VAC, 50 Hz, 4-wire) |
| Nominal noise level | 69 dB(A) | (on 1 meter distance) |
| Dimensions | 2130 x 1270 x 1990 | (WxDxH in mm) |
| Weight | 805 kg | (Including insulations) |
The AFIM Dry 5000 desiccant dehumidifier is standard equipped with a flow controlled control of the process fan, so filter pollution does not affect the operation of the dehumidifier. In addition, the dehumidifier is suitable for use in industrial environments and is equipped with filters that contain up to 5x higher dust absorption capacity.
By applying EC technology in combination with both internal heat recovery (standard) and also the possibility for external heat recovery (optional), the AFIM Dry is one of the most energy-efficient dehumidifiers on the market.
Standard for the AFIM Dry 5000
- Suitable for industrial environments
- Fully insulated and unique thermal bridge-free housing
- Analog controller (suitable for 0-10 Volt DC)
- No hindrance from filter pollution due to constant volume control
- Low maintenance costs due to filters with up to 5 times higher dust absorption capacity
- Suitable for application within the food and pharmaceutical industry and storage applications
- Internal heat recovery (energy saving up to 15% compared to market standard)
- Suitable for very low dew points (up to -60ºC dp)
- Various adjustable digital calendar clocks
- Filter alarm
- Rotor rotation guard
- Digital alarm history including time and date stamp
- Different operating hours counters (individual for each main component in the dehumidifier)
- Original Dutch product
Optional for the AFIM Dry 5000
- External heat recovery (energy saving up to 43% compared to market standard)
- Fully executed in stainless steel 304 or 316
- 5 year warranty extension
- Online assistance
- Online monitoring
| Technical specifications | ||
|---|---|---|
| Dehumidification capacity | 50 kg/h | (at +20°C and 60% RH) |
| Process airflow | 5000 m3/h | (at 500 Pa external pressure available) |
| Regeneration airflow | 1600 m3/h | (at 1000 Pa external pressure available) |
| Filter class | ePM1 50% (F7) | (according to ISO standard 16890) |
| Heater power | 49,5 kW | (maximum) |
| Electrical power supply | 56 kW | (3× 400 VAC, 50 Hz, 4-wire) |
| Nominal noise level | 69 dB(A) | (on 1 meter distance) |
| Dimensions | 2130 x 1370 x 2090 | (WxDxH in mm) |
| Weight | 815 kg | (Including insulations) |
The AFIM Dry 10K desiccant dehumidifier is standard equipped with a flow controlled control of the process fan, so filter pollution does not affect the operation of the dehumidifier. In addition, the dehumidifier is suitable for use in industrial environments and is equipped with filters that contain up to 5x higher dust absorption capacity.
By applying EC technology in combination with both internal heat recovery (standard) and also the possibility for external heat recovery (optional), the AFIM Dry is one of the most energy-efficient dehumidifiers on the market.
Standard for the AFIM Dry 10K
- Suitable for industrial environments
- Fully insulated and unique thermal bridge-free housing
- Analog controller (suitable for 0-10 Volt DC)
- No hindrance from filter pollution due to constant volume control
- Low maintenance costs due to filters with up to 5 times higher dust absorption capacity
- Suitable for application within the food and pharmaceutical industry and storage applications
- Internal heat recovery (energy saving up to 15% compared to market standard)
- Suitable for very low dew points (up to -60ºC dp)
- Various adjustable digital calendar clocks
- Filter alarm
- Rotor rotation guard
- Digital alarm history including time and date stamp
- Different operating hours counters (individual for each main component in the dehumidifier)
- Original Dutch product
Optional for the AFIM Dry 10K
- External heat recovery (energy saving up to 43% compared to market standard)
- Fully executed in stainless steel 304 or 316
- 5 year warranty extension
- Online assistance
- Online monitoring
| Technical specifications | ||
|---|---|---|
| Dehumidification capacity | 70 kg/h | (at +20°C and 60% RH) |
| Process airflow | 10000 m3/h | (at 500 Pa external pressure available) |
| Regeneration airflow | 2700 m3/h | (at 1000 Pa external pressure available) |
| Filter class | ePM1 50% (F7) | (according to ISO standard 16890) |
| Heater power | 76,5 kW | (maximum) |
| Electrical power supply | 92 kW | (3× 400 VAC, 50 Hz, 4-wire) |
| Nominal noise level | 69 dB(A) | (on 1 meter distance) |
| Dimensions | 2620 x 1765 x 2085 | (WxDxH in mm) |
| Weight | 1395 kg | (including insulations) |
